ATB-MCCB 1000V DC Moulded Case Circuit Breaker

ATB-MCCB 1000V DC Moulded Case Circuit Breaker
ATB-MCCB 1000V DC Moulded Case Circuit Breaker

Features & Benefits

Reliable protection at high ambient temperatures

Loadable:string protectionup to
125 size:63A,80A, 100A,125A
250 size:100A, 125A, 160A,200A,225A,250A
400 size:200A,225A,250A,315A, 400A,
630 size:400A. 500A,630A,
1250size:630A,800A, 1000A, 1250A,

Tested:Ultimate short circuit breaking capacity lcu of 25kA according to IEC IEC60947-2

Fast: reclosable for minmum standstill times

Safe: reliable disconnector properties,switching under load

Approval:Provided on pequest

Inquiry Download
Share to
Product Details
Specifications
Rated Current In (A) 125:63A, 80A, 100A, 125A, 250:160A, 200A, 225A, 250A, 400:200A, 225A, 250A, 315A, 400A
630:400A, 500A, 630A, 1250:630A, 800A, 1000A, 1250A
Ue Rated operating voltage (VDC) 3P 750V 4P DC1000V
Rated insulation voltage Ui (VDC) DC1000V
Rated Impact voltage Uimp (kV) 8KV
Ultimate breaking capacity Icu (kV) 25KV
Trip type Thermal-magnetic
Ambient temperature (9C) -20°C ~70°C
Atitude 2000M
Instalation Fixed, plug-in
Accessories Auxiliary, Alarm, Shunt release, Manually operated and electric operation



Wiring diagram

●Protection and lsolation wiring

●The load should be≤DC1000V
The connection considered for anetwork in which the middle point of the supply source is earthed, In this case the breaker protects and isolates the load

●Protection and lsolation wiring

●The load should be≤DC1000V
The Negative pole (-) could be earthed,but in both cases the breaker protects and isolates the load



Curve chart



Installation dimensions

*400A installation dimensions please contact manufacturers



Type Dimensions installation size
Front panel wiring Wiring behind the board
W L H W1 L1 H1 H2 H3 L2 H4 L5 A B ψd
CLBM1Z-100M 92 15W0 86 60 185 104 24 24 132 68 108 30 129 4.5
CLBM1Z-100H
CLBM1Z-250M 107 165 103 70 215 127 24 24 144 66 110 35 126 5
CLBM1Z-250H 44
CLBM1Z-400M 150 257 105 96 370 155 38 38 224 60 120 58 194 7
CLBM1Z-400H
CLBM1Z-630M 182 270 110 116 370 160 43 43 234 65 125 58 200 7
CLBM1Z-630H
CLBM1Z-800M 210 280 106 140 380 145 33 30 234 128 70 243 7.3
CLBM1Z-800H
